Ensign 6 Pacemaker
Ensign Radio, The Electric Lamphouse Ltd.; Wellington
- Country
- New Zealand-Aotearoa
- Manufacturer / Brand
- Ensign Radio, The Electric Lamphouse Ltd.; Wellington
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 346541
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 inch = 16.5 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Ensign 6 Pacemaker - Ensign Radio, The Electric
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 17 x 11 x 8.25 inch / 432 x 279 x 210 mm
- Notes
-
6-Valve superhet with RF stage broadcast (MW) table receiver.
6 1/2" Anisotropic Alnico Rola PM speaker, built in aerial & earth. Veneered cabinet.
Manufactured for Electric Lamp House Ltd by Collier & Beale Ltd.
See also Pacemaker 617P.
- Price in first year of sale
- 28.50 NZ £
- Mentioned in
- -- Original prospect or advert (Lamphouse Annual 1948-49 Page 31 (World Radio History))
- Author
- Model page created by Brian Stevens. See "Data change" for further contributors.
