Einschubempfänger Oberon 1142.14
Funkwerk Kölleda, VEB, RFT, - vorm. Neutrowerk, Neutro-Werk (Ostd.)
- Country
- Germany
- Manufacturer / Brand
- Funkwerk Kölleda, VEB, RFT, - vorm. Neutrowerk, Neutro-Werk (Ostd.)
- Year
- 1961 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 318565
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Number of Transistors
- Semiconductors
- Selengleichrichter
- Main principle
- Superheterodyne (common); ZF/IF 473/10700 kHz
- Tuned circuits
- 8 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Einschubempfänger Oberon 1142.14 - Funkwerk Kölleda, VEB, RFT, -
- Shape
- Chassis only or for «building in»
- Notes
-
Chassis als Gestelleinschub des Oberon 1131.053 von Stern-Radio Rochlitz für für ELA-Anlagen vom Funkwerk Kölleda.
Nachfolgetyp des Einschubempfängers 11E92S Typ 1340.16.Regelbarer 10-Ω-NF-Ausgang, erdfrei 3,2 V und 100-V-Normausgang über Messerleisten.
- Net weight (2.2 lb = 1 kg)
- 10.3 kg / 22 lb 11 oz (22.687 lb)
- Mentioned in
- -- Schematic
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
