• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1961/1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 157899

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EM84 EL84

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 7 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 115; 220 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 2260U - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 540 x 314 x 217 mm / 21.3 x 12.4 x 8.5 inch

• Notes
• Grundig 2260U;
  US export model,
  FM: 88 - 108 MHz,
  BC: 550 - 1600 KHz,
  SW1: ~3 - 8.5 MHz,
  SW2: ~8.5 - 22 MHz,
  two tone equalizer buttons, bass & treble control, tuning indicator tube, phono/tape DIN terminal in, ext. speaker terminal, int. FM dipole, terminals for AM/earth & FM antenna in, made in W. Germany, front labeled with Grundig "2260" sticker only,
  compare with German domestic version Musikgerät 2260.

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
