Micro-Boy 300a

Micro-Boy 300a; Grundig Radio- (ID = 237637) Radio
Micro-Boy 300a; Grundig Radio- (ID = 1305338) Radio Micro-Boy 300a; Grundig Radio- (ID = 108816) Radio
Micro-Boy 300a; Grundig Radio- (ID = 296774) Radio Micro-Boy 300a; Grundig Radio- (ID = 347727) Radio
Micro-Boy 300a; Grundig Radio- (ID = 296775) Radio Micro-Boy 300a; Grundig Radio- (ID = 64740) Radio
Micro-Boy 300a; Grundig Radio- (ID = 108817) Radio Micro-Boy 300a; Grundig Radio- (ID = 385529) Radio
Micro-Boy 300a; Grundig Radio- (ID = 446626) Radio Micro-Boy 300a; Grundig Radio- (ID = 446627) Radio
Use red slider bar for more.
Micro-Boy 300a; Grundig Radio- (ID = 1305338) Radio
Grundig Radio-: Micro-Boy 300a [Radio] ID = 1305338 933x1288
Select picture or schematic to display from thumbnails on the right and click for download.
For model Micro-Boy 300a, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1973–1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / AA: 2 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Micro-Boy 300a - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 70 x 110 x 30 mm / 2.8 x 4.3 x 1.2 inch
Notes

1 Diode; Gehäusefarben: Weiss, Rot, Schwarz.

In Katalogen und Prospekten nur als Micro-Boy 300 bezeichnet.

Siehe auch Grundig Micro-Boy 300 mit Batteriebestückung 1 x 9 V.

Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 25.00 DM
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1973/1974
Mentioned in Handbuch VDRG 1974/1975 (und bis 1977/78)
Literature/Schematics (1) Radio es Televizio Vevö keszülekek 1972-75
