Musikschrank 8060WF/3D

Musikschrank 8060WF/3D; Grundig Radio- (ID = 245322) Radio
Musikschrank 8060WF/3D; Grundig Radio- (ID = 245323) Radio
Musikschrank 8060WF/3D; Grundig Radio- (ID = 2165959) Radio Musikschrank 8060WF/3D; Grundig Radio- (ID = 2165960) Radio
Use red slider bar for more.
Musikschrank 8060WF/3D; Grundig Radio- (ID = 2165959) Radio
Grundig Radio-: Musikschrank 8060WF/3D [Radio] ID = 2165959 1200x966
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musikschrank 8060WF/3D, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Q: Grundig, Produkt-Katalog '55
Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name
Grundig Portugal || Grundig USA / Lextronix
Year: 1957 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: ECC85 ECH81 EF89 EF80 EM34 or EM35 EABC80 EBC41 EL84 EL84
Main principle Superheterodyne (common); ZF/IF 468 kHz; 3 AF stage(s)
Tuned circuits 8 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Power type and voltage Alternating Current supply (AC) / 110; 125; 160; 220 Volt
Loudspeaker 6 Loudspeakers
Power out
from Model: Musikschrank 8060WF/3D - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with Push Buttons.
Literature/Schematics (1) Lange, Schaltungen der Funkindustrie

Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
