TK46b

TK46b; Grundig Radio- (ID = 399775) R-Player TK46b; Grundig Radio- (ID = 399779) R-Player
TK46b; Grundig Radio- (ID = 399778) R-Player TK46b; Grundig Radio- (ID = 399776) R-Player
TK46b; Grundig Radio- (ID = 399777) R-Player TK46b; Grundig Radio- (ID = 399780) R-Player
TK46b; Grundig Radio- (ID = 653795) R-Player TK46b; Grundig Radio- (ID = 653796) R-Player
TK46b; Grundig Radio- (ID = 653797) R-Player TK46b; Grundig Radio- (ID = 653798) R-Player
Use red slider bar for more.
TK46b; Grundig Radio- (ID = 399775) R-Player
Grundig Radio-: TK46b [R-Player] ID = 399775 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model TK46b, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1965 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 8: EF86 EF86 ECC81 ECC81 EM84 ECC83 ELL80 EL95
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: TK46b - Grundig Radio-Vertrieb, RVF,
Material Leather / canvas / plastic - over other material
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 510 x 210 x 400 mm / 20.1 x 8.3 x 15.7 inch
Notes Deckplatte oben in ähnlicher Farbe wie der Koffermittelteil, internationale Version, Spulen-Ø 18 cm, Vierspur Stereo, 4,75/9,5/19 cm/s; 2 Dioden, Tr.Gl.=B250C100.
Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
Collectors' prices
Source of data -- Collector info (Sammler)

Model page created by Urs Gloor. See "Data change" for further contributors.
