• Country
• Germany

• Manufacturer / Brand
• Heucke, W., Techn. Labor (TLH); Berlin und Viernheim

• Year
• 1963 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 87054

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• EF80 ECH81 ECC81 ECC83 E88CC E81L EL84 EAA91 90C1 150C2 452 DG13-32

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 235 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Wobbel-Messplatz 205 Multivisor - Heucke, W., Techn. Labor TLH;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 290 x 360 x 455 mm / 11.4 x 14.2 x 17.9 inch

• Notes
• Wobbelsender, Breitband-Oszillograph und Eichgenerator mit Quarz.
  Frequenzbereich 12 Bänder zu 12 MHz Breite; 24 MHz oder 36 MHz (ZF); 51...65 MHz(Kanal 2...4); 94 MHz(UKW); 178...220 MHz(Kanal 5...11); (8 MHz Mittelfrequenz ± 6 MHz for FM-ZF).
  Röhren teilweise mehrfach.

• Net weight (2.2 lb = 1 kg)
• 20 kg / 44 lb 0.8 oz (44.053 lb)

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Eero Ukkola. See "Data change" for further contributors.
