Attaché W467A /1

Attaché W467A /1; Horny Hornyphon; (ID = 71170) Radio

Attaché W467A /1; Horny Hornyphon; (ID = 943550) Radio

Attaché W467A /1; Horny Hornyphon; (ID = 943551) Radio

Attaché W467A /1; Horny Hornyphon; (ID = 662050) Radio

Attaché W467A /1; Horny Hornyphon; (ID = 662051) Radio
Attaché W467A /1; Horny Hornyphon; (ID = 655379) Radio Attaché W467A /1; Horny Hornyphon; (ID = 655380) Radio
Attaché W467A /1; Horny Hornyphon; (ID = 655381) Radio Attaché W467A /1; Horny Hornyphon; (ID = 71169) Radio
Attaché W467A /1; Horny Hornyphon; (ID = 288801) Radio
Use red slider bar for more.
Attaché W467A /1; Horny Hornyphon; (ID = 655379) Radio
Horny Hornyphon;: Attaché W467A /1 [Radio] ID = 655379 800x533
Select picture or schematic to display from thumbnails on the right and click for download.
For model Attaché W467A /1, Horny (Hornyphon); Wien:
eigene Sammlung

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF85 EABC80 EM81 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Attaché W467A /1 - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 490 x 315 x 225 mm / 19.3 x 12.4 x 8.9 inch
Notes

Hornyphon Attaché W467A /1 - Klangtastenschalter mit 5 Tasten

2 weitere Ausführungen:
Hornyphon Prinz 57 W467A   = ohne Klangtastenschalter
Hornyphon Super-Prinz W467A /2 = Klangtastenschalter mit 3 Tasten.

Parallelgerät zum Philips Bolero B4A73A.

Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Museums Bote, Österr. (Heft 19/1990, S.3, erwähnt in Firmengechichte)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Gerhard Heigl. See "Data change" for further contributors.



All listed radios etc. from Horny (Hornyphon); Wien
Here you find 867 models, 774 with images and 581 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
