Primas ; Kapsch & Söhne KS, (ID = 808398) Radio
Kapsch & Söhne KS,: Primas [Radio] ID = 808398 933x641
Select picture or schematic to display from thumbnails on the right and click for download.
For model Primas, Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien:
Sammlung Peter Roggenhofer

Country:  Austria
Manufacturer / Brand:  Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 461/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Primas - Kapsch & Söhne KS, Telephon-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 420 x 270 x 205 mm / 16.5 x 10.6 x 8.1 inch
Notes Anschlüsse für Plattenspieler und Tonbandgerät.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 1'695.00 ATS
Mentioned in Museums Bote, Österr. (Heft 121/2004, S.12, Kurzbeschreibung)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
