Tarantella Ch= Telefunken Rondo 55
Use red slider bar for more.
Kuba Kuba-Imperial,: Tarantella Ch= Telefunken Rondo 55 [Radio] ID = 1917331 1400x945
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Imperial Kuba | ||||
|---|---|---|---|---|---|
| Year: 1954/1955 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: ECC85 ECH81 EF89 EABC80 EM80 EL84 |
| Main principle | Superheterodyne (common); ZF/IF 460/10700 kHz |
|---|---|
| Tuned circuits | 8 AM circuit(s) 9 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | Changer (Record changer) |
| Power type and voltage | Alternating Current supply (AC) / 110; 220 Volt |
| Loudspeaker | |
| Power out | 4 W (unknown quality) |
| from Radiomuseum.org | Model: Tarantella Ch= Telefunken Rondo 55 - Kuba Kuba-Imperial, G. |
| Material | Wooden case |
| Shape | Console with Push Buttons. |
| Dimensions (WHD) | 870 x 760 x 420 mm / 34.3 x 29.9 x 16.5 inch |
| Notes | Rundfunk-Chassis = Telefunken Rondo 55 Siehe einige weitere Modellbelätter für gleiche Gehäuse mit anderen Chassis, z.B. von Nordmende. |
| Price in first year of sale | 748.00 DM |
| Source of data | HdB d.Rdf-& Ferns-GrH 1954/55 |
Model page created by Bernd P. Kieck. See "Data change" for further contributors.
All listed radios etc. from Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
Here you find 727 models, 672 with images and 257 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
