Hellas 3842W
Loewe-Opta;: Hellas 3842W [Radio] ID = 1738969 1077x808
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Löwe Radio | ||||
|---|---|---|---|---|---|
| Year: 1958/1959 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 11: ECC85 ECH81 EF89 EF89 EM84 EM84 ECC83 ECC81 EL84 EL84 ECL82 | ||||
| Semiconductors (the count is only for transistors) | DN95 OA150 OA150 OA150 B250C150 |
| Main principle | Superheterodyne (common); ZF/IF 460 kHz |
|---|---|
| Tuned circuits | 11 AM circuit(s) 14 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110-240 Volt |
| Loudspeaker | 4 Loudspeakers |
| Power out | |
| from Radiomuseum.org | Model: Hellas 3842W - Loewe-Opta; Deutschland |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 710 x 410 x 330 mm / 28 x 16.1 x 13 inch |
| Net weight (2.2 lb = 1 kg) | 18.4 kg / 40 lb 8.5 oz (40.529 lb) |
Model page created by Volker Friedrich. See "Data change" for further contributors.
