Komet 1782W

Komet 1782W; Loewe-Opta; (ID = 52484) Radio

Komet 1782W; Loewe-Opta; (ID = 52489) Radio

Komet 1782W; Loewe-Opta; (ID = 52494) Radio

Komet 1782W; Loewe-Opta; (ID = 487822) Radio
Komet 1782W; Loewe-Opta; (ID = 231090) Radio Komet 1782W; Loewe-Opta; (ID = 231091) Radio
Komet 1782W; Loewe-Opta; (ID = 133358) Radio Komet 1782W; Loewe-Opta; (ID = 84668) Radio
Komet 1782W; Loewe-Opta; (ID = 84389) Radio Komet 1782W; Loewe-Opta; (ID = 59234) Radio
Komet 1782W; Loewe-Opta; (ID = 133359) Radio Komet 1782W; Loewe-Opta; (ID = 133360) Radio
Komet 1782W; Loewe-Opta; (ID = 133361) Radio Komet 1782W; Loewe-Opta; (ID = 246261) Radio
Use red slider bar for more.
Komet 1782W; Loewe-Opta; (ID = 231090) Radio
Loewe-Opta;: Komet 1782W [Radio] ID = 231090 933x619
Select picture or schematic to display from thumbnails on the right and click for download.
For model Komet 1782W, Loewe-(Opta); Deutschland:
Mit eingeschalteter Schallwandbeleuchtung

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF85 EABC80 EM80 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 473/10700 kHz
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220 Volt
Loudspeaker 3 Loudspeakers
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Komet 1782W - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 600 x 395 x 285 mm / 23.6 x 15.6 x 11.2 inch
Notes ZF auch 464 kHz; drehbare Ferritantenne.
Net weight (2.2 lb = 1 kg) 13.5 kg / 29 lb 11.8 oz (29.736 lb)
Price in first year of sale 399.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57
