Luna-Phono 1743Ph/W

Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 450594) Radio

Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 52398) Radio
Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 2503045) Radio Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 2503047) Radio
Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 2503048) Radio Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 2503044) Radio
Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 2503050) Radio Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 100184) Radio
Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 100182) Radio Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 100183) Radio
Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 100180) Radio Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 100181) Radio
Use red slider bar for more.
Luna-Phono 1743Ph/W; Loewe-Opta; (ID = 2503045) Radio
Loewe-Opta;: Luna-Phono 1743Ph/W [Radio] ID = 2503045 1400x1562
Select picture or schematic to display from thumbnails on the right and click for download.
For model Luna-Phono 1743Ph/W, Loewe-(Opta); Deutschland:
Loewe-Opta Luna-Phono1743Ph-W offen

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM80 EL84
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220 Volt
Loudspeaker 3 Loudspeakers
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: Luna-Phono 1743Ph/W - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 555 x 370 x 340 mm / 21.9 x 14.6 x 13.4 inch
Notes Phono-Chassis = Perpetuum-Ebner 3420PE.
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Price in first year of sale 429.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57


All listed radios etc. from Loewe-(Opta); Deutschland
Here you find 1582 models, 1307 with images and 1154 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Loewe-Opta;: Luna-Phono 1743Ph/W
Threads: 2 | Posts: 3
Hits: 1610     Replies: 0
loewe-opta: 1743Ph/W; Luna-Phono
Peter Breu
21.Jan.13
  1

Hallo wer kann mir bei der Reparatur eines PE-Plattenspielers weiterhelfen.

Ich habe den Antriebsgummi erneuert und die Lager neu geschmiert. Ausserdem den Hilfskondensator am Motor erneuert.

Leider dreht der Plattenteller immer noch zu langsam!

Kann es evtl. am Treibrad liegen (harter Gummi?)



Gruß

Peter Breu


Hits: 2055     Replies: 1
loewe-opta: 1743Ph/W ; Luna-Phono
Wally Wilson
11.Mar.11
  1

I just got a Luna 1743Ph/W (with Phono). I have the schematic, but am not certain of the locations of the tubes. Someone has been into it and moved them around so I and need the locations as viewed from the back, left to right. Can anyone help me, please?

Wally Wilson

Hans M. Knoll
16.Mar.11
  2

Hello Mr. Wilson.



See this Location

regards knoll


Loewe-Opta;: Luna-Phono 1743Ph/W
