Premiär 3096 WD Ch= 5601 W
Luxor Radio AB; Motala
- Country
- Sweden
- Manufacturer / Brand
- Luxor Radio AB; Motala
- Year
- 1956 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 349362
-
- alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 462/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 11 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 250 Volt
- Loudspeaker
- 3 Loudspeakers
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Premiär 3096 WD Ch= 5601 W - Luxor Radio AB; Motala
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 530 x 340 x 250 mm / 20.9 x 13.4 x 9.8 inch
- Notes
-
Main loudspeaker elliptical 26x16 cm, Two 5" side oriented speakers
- Net weight (2.2 lb = 1 kg)
- 11.5 kg / 25 lb 5.3 oz (25.33 lb)
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Ola Gröndalen. See "Data change" for further contributors.
