• Country
• Italy

• Manufacturer / Brand
• Minerva (Ital-Minerva); Milano

• Year
• 1955–1958

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 232592

• • alternative name: Cozzi Luigi Dell'Aquila

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 23

• Valves / Tubes
• ECC84 ECF80 ECF80 EF80 EF80 EF80 EF80 EF80 EF80 EABC80 ECC82 ECC82 ECC82 EL81 EL83 EL84 EL84 EB91 EY81 DY86 PY82 PY82 MW43-64

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 125; 140; 160; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Material
• Various materials

• from Radiomuseum.org
• Model: 5543/1 - Minerva Ital-Minerva; Milano

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 520 x 480 x 460 mm / 20.5 x 18.9 x 18.1 inch

• Notes

• Come i primi televisori riceveva solo le trasmissioni in VHF ed era predisposto per l'installazione di un sintonizzatore per ricevere la UHF.

  CRT: Philips MW43/64 17"

  Only VHF. Possibility to install UHF.

  Materials: bakelite and wood.

• Price in first year of sale
• 170,000.00 ITL

• Author
• Model page created by Manuel Zenato. See "Data change" for further contributors.
