Belvedere SR

Belvedere SR; Nora; Berlin (ID = 352833) TV Radio

Belvedere SR; Nora; Berlin (ID = 352834) TV Radio

Belvedere SR; Nora; Berlin (ID = 352835) TV Radio

Belvedere SR; Nora; Berlin (ID = 352836) TV Radio
Belvedere SR; Nora; Berlin (ID = 1177646) TV Radio Belvedere SR; Nora; Berlin (ID = 313319) TV Radio
Belvedere SR; Nora; Berlin (ID = 403383) TV Radio
Use red slider bar for more.
Belvedere SR; Nora; Berlin (ID = 1177646) TV Radio
Nora; Berlin: Belvedere SR [TV Radio] ID = 1177646 650x867
Select picture or schematic to display from thumbnails on the right and click for download.
For model Belvedere SR, Nora; Berlin

Country:  Germany
Manufacturer / Brand:  Nora; Berlin
Year: 1954/1955 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 18: PCC84 ECC81 EF80 PL83 PCF82 ECL80 PCL81 EAA91 ECC82 PL81 PY81 PABC80 PL82 EY51 MW43-64
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Belvedere SR - Nora; Berlin
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 580 x 1000 x 550 mm / 22.8 x 39.4 x 21.7 inch
Notes TV-Röhren teilweise mehrfach vorhanden. 10 VHF-Kanäle + 2 Reserve.
Rundfunkteil: LMKU, 6 AM- und 9 FM-Kreise; EF80, EC92, ECH81 EF41, EM80, EABC80, EL84.
Net weight (2.2 lb = 1 kg) 55 kg / 121 lb 2.3 oz (121.145 lb)
Price in first year of sale 1'495.00 DM
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
