188-WU; Nordmende, (ID = 845511) Radio
Nordmende,: 188-WU [Radio] ID = 845511 933x592
Select picture or schematic to display from thumbnails on the right and click for download.
For model 188-WU 7 Röhren, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
Sammlung

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECH42 EF41 EF42 EB41 EM34 EBF80 EL41
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general); ZF/IF 473/10700 kHz; 2 AF stage(s)
Tuned circuits 8 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: 188-WU [7 Röhren] - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 620 x 390 x 260 mm / 24.4 x 15.4 x 10.2 inch
Notes

Nordmende 188 WU in der frühen Ausführung mit 7 Röhren und ohne UKW-Vorstufe. Das Gerät ist eine Weiterentwicklung des 415W.

7 Wellenbereiche:
UKW: 85...102 MHz, eingebaute UKW-Antenne.
4 KW-Bereiche mit 20-facher Bandspreizung:
49m Band (5,93 - 6,35 MHz)
41m Band (7,01 - 7,57 MHz)
31m Band (9,42 - 10,15 MHz
25m Band (11,57 - 12,4 MHz)
Mittelwelle und Langwelle

Siehe auch die 8-Röhren-Variante 188 WU mit zusätzlicher EF42 im UKW-Eingang.

Net weight (2.2 lb = 1 kg) 12.3 kg / 27 lb 1.5 oz (27.093 lb)
Price in first year of sale 438.00 DM
Collectors' prices
Source of data Kat.d.Rundf.GrossH.1951/52
Mentioned in -- Original prospect or advert

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
