Tannhäuser 55 Ch= 412; Nordmende, (ID = 7117) Radio
Nordmende,: Tannhäuser 55 Ch= 412 [Radio] ID = 7117 876x547
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tannhäuser 55 Ch= 412, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: EC92 EC92 ECH81 EF85 EM34 or EM35 EABC80 EC92 EL84 EL84
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out 12 W (unknown quality)
from Radiomuseum.org Model: Tannhäuser 55 Ch= 412 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 675 x 415 x 275 mm / 26.6 x 16.3 x 10.8 inch
Net weight (2.2 lb = 1 kg) 14 kg / 30 lb 13.4 oz (30.837 lb)
Price in first year of sale 438.00 DM
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
Literature/Schematics (1) -- Original-techn. papers.
