For model Expo 58 2079, Novak (also Pontiac); Bruxelles:
ORM bibliotheek

Country:  Belgium
Manufacturer / Brand:  Novak (also Pontiac); Bruxelles
Year: 1958 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: PCC84 PCF80 EF85 EF85 PABC80 EF80 PL82 EF80 EF80 EF80 EF80 PL83 PCF80 PCF80 PCL82 ECC82 PL36 PY83 or PY81 EY86 AW53-80
Semiconductors (the count is only for transistors) OA70 OA70 OA161 OA161 OA161 OA161 OA72 OA72
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Expo 58 2079 - Novak also Pontiac; Bruxelles
Material Wooden case
Shape Console with Push Buttons.
Notes

Unit uses 8 additional germanium diodes.
VHF only - 12 channels
4 standards (819F, 819B, 625B, 625 CCIR) selectable by rotating combination switches.
2 loudspeakers of which 1 tweeter.
Cabinet in polished walnut and sycomore with 2 front doors. Key locking.

Price in first year of sale 19'900.00 BEF
Source of data -- Original-techn. papers.
Mentioned in -- Original prospect or advert

Model page created by Dirk Bladt. See "Data change" for further contributors.
