Pacsirta (Lerche) AR612-144 Export LW

Orion; Budapest

  • Year
  • 1960 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 268238

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 473,5/10700 kHz
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Pacsirta AR612-144 Export LW - Orion; Budapest
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 690 x 410 x 300 mm / 27.2 x 16.1 x 11.8 inch
  • Notes
  • Fünf Wellenbereiche (Meterangaben gemäß Skala)

    LW 940-2000 m
    MW 187-575 m
    KW 1 26.1-52 m
    KW 2 13.7-26.1 m
    UKW 3-3,4 m ( Skala in MHz etwa 87-101 )

    Skala im verdeckten Bereich links unten 'AR 612-144', rechts unten 'EN 146R'

  • Net weight (2.2 lb = 1 kg)
  • 15 kg / 33 lb 0.6 oz (33.04 lb)
  • Literature/Schematics (4)
  • -- Schematic
  • Author
  • Model page created by Manfred Rathgeb. See "Data change" for further contributors.
