B4X23A /74; Philips Belgium (ID = 2300221) Radio
Philips Belgium: B4X23A /74 [Radio] ID = 2300221 1400x756
Select picture or schematic to display from thumbnails on the right and click for download.
For model B4X23A /74, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF85 EABC80 EM80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 145; 220 Volt
Loudspeaker 2 Loudspeakers / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: B4X23A /74 - Philips Belgium Belgien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 550 x 230 x 210 mm / 21.7 x 9.1 x 8.3 inch
Notes Philips B4X23A/74;
Gehäuseseiten aus Kunststoff, Frequenzbereich UKW von 87,5-108 MHz.

Model page created by Michael Mehnert. See "Data change" for further contributors.
