B5CH63A

B5CH63A; Philips - Schweiz (ID = 926390) Radio B5CH63A; Philips - Schweiz (ID = 926389) Radio
B5CH63A; Philips - Schweiz (ID = 926391) Radio B5CH63A; Philips - Schweiz (ID = 926392) Radio
Use red slider bar for more.
B5CH63A; Philips - Schweiz (ID = 926390) Radio
Philips - Schweiz: B5CH63A [Radio] ID = 926390 933x596
Select picture or schematic to display from thumbnails on the right and click for download.
For model B5CH63A, Philips - Schweiz

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: ECC85 ECH81 EF89 EF85 EM80 EABC80 EL84 EL86 EZ80
Main principle Superhet with RF-stage; ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 145; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: B5CH63A - Philips - Schweiz
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 620 x 430 x 260 mm / 24.4 x 16.9 x 10.2 inch
Notes Thermosicherung und 3 Feinsicherungen.
Drehbare Doppelferritantenne. Durchmesser des Hauptlautsprechers: 22cm.

Model page created by Ottmar Lauth. See "Data change" for further contributors.
