For model BCH462A mit UKW, Philips - Schweiz

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EF85 EM80 EABC80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: BCH462A [mit UKW] - Philips - Schweiz
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes

Philips BCH462A (1956) ist nicht identisch mit BCH462A Rigoletto (1946).

Ähnliche Modelle:
- H5CH60A (ID77327) mit Plattenspieler AG2004
- B4CH61A ohne KW-Bereich
- B4CH66A (ID86901) mit Hochtonlautsprecher 9766AMS


Source of data -- Original-techn. papers.

Model page created by Marc Gianella. See "Data change" for further contributors.
