For model BS461A, Philips, Svenska AB, Stockholm

Country:  Sweden
Manufacturer / Brand:  Philips, Svenska AB, Stockholm
Year: 1957 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EBF80 EF89 EM80 EABC80 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10850 kHz
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110;127;220;240 Volt
Loudspeaker 2 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: BS461A - Philips, Svenska AB, Stockholm
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 525 x 340 x 236 mm / 20.7 x 13.4 x 9.3 inch
Notes

The radio has a frame antenna in the rear rim of the cabinet.

Two loudspeakers: Main speaker 17 cm diameter 9766M and high frequency speaker 13 cm diameter 9768M. Speakers connected in parallel.

Net weight (2.2 lb = 1 kg) 11.2 kg / 24 lb 10.7 oz (24.67 lb)

Model page created by Ola Gröndalen. See "Data change" for further contributors.
