BX548A

BX548A; Philips Belgium (ID = 1045792) Radio

BX548A; Philips Belgium (ID = 1045793) Radio

BX548A; Philips Belgium (ID = 1045794) Radio

BX548A; Philips Belgium (ID = 1045795) Radio

BX548A; Philips Belgium (ID = 1045796) Radio

BX548A; Philips Belgium (ID = 1045797) Radio

BX548A; Philips Belgium (ID = 1045798) Radio

BX548A; Philips Belgium (ID = 1045803) Radio

BX548A; Philips Belgium (ID = 1045804) Radio

BX548A; Philips Belgium (ID = 1045805) Radio
BX548A; Philips Belgium (ID = 1030819) Radio BX548A; Philips Belgium (ID = 1030821) Radio
BX548A; Philips Belgium (ID = 1030822) Radio BX548A; Philips Belgium (ID = 1030823) Radio
Use red slider bar for more.
BX548A; Philips Belgium (ID = 1030819) Radio
Philips Belgium: BX548A [Radio] ID = 1030819 900x685
Select picture or schematic to display from thumbnails on the right and click for download.
For model BX548A, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EBF80 EF85 EM80 EABC80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 90; 110; 125; 150; 200; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: BX548A - Philips Belgium Belgien
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 520 x 340 x 210 mm / 20.5 x 13.4 x 8.3 inch
Notes Dial lamp: 8024N (6,3V/0,3A).

Model page created by Júlio Branco. See "Data change" for further contributors.
