F5X62A

F5X62A; Philips; Eindhoven (ID = 43786) Radio

F5X62A; Philips; Eindhoven (ID = 43787) Radio

F5X62A; Philips; Eindhoven (ID = 43788) Radio

F5X62A; Philips; Eindhoven (ID = 43789) Radio

F5X62A; Philips; Eindhoven (ID = 43793) Radio

F5X62A; Philips; Eindhoven (ID = 43795) Radio

F5X62A; Philips; Eindhoven (ID = 43796) Radio

F5X62A; Philips; Eindhoven (ID = 43797) Radio

F5X62A; Philips; Eindhoven (ID = 43798) Radio

F5X62A; Philips; Eindhoven (ID = 43799) Radio
F5X62A; Philips; Eindhoven (ID = 135586) Radio F5X62A; Philips; Eindhoven (ID = 135591) Radio
F5X62A; Philips; Eindhoven (ID = 135587) Radio F5X62A; Philips; Eindhoven (ID = 135588) Radio
F5X62A; Philips; Eindhoven (ID = 135592) Radio F5X62A; Philips; Eindhoven (ID = 135593) Radio
F5X62A; Philips; Eindhoven (ID = 778071) Radio
Use red slider bar for more.
F5X62A; Philips; Eindhoven (ID = 135586) Radio
Philips; Eindhoven: F5X62A [Radio] ID = 135586 476x604
Select picture or schematic to display from thumbnails on the right and click for download.
For model F5X62A, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: ECC85 ECH81 EF89 EF85 EM80 EABC80 EL84 EL86 EZ81
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 6 W (unknown quality)
from Radiomuseum.org Model: F5X62A - Philips; Eindhoven tubes
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 605 x 875 x 400 mm / 23.8 x 34.4 x 15.7 inch
Notes

Plattenspieler AG1003-75

Siehe auch Philips F5X62A/02 mit Tonbandgerät AG8001/05 bzw. AG8007.

Price in first year of sale 798.00 Dfl
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
