Party L3A12T /00S /00G

Party L3A12T /00S /00G; Philips - Österreich (ID = 70875) Radio

Party L3A12T /00S /00G; Philips - Österreich (ID = 934810) Radio

Party L3A12T /00S /00G; Philips - Österreich (ID = 70876) Radio
Party L3A12T /00S /00G; Philips - Österreich (ID = 467367) Radio Party L3A12T /00S /00G; Philips - Österreich (ID = 152918) Radio
Party L3A12T /00S /00G; Philips - Österreich (ID = 276925) Radio Party L3A12T /00S /00G; Philips - Österreich (ID = 778609) Radio
Party L3A12T /00S /00G; Philips - Österreich (ID = 778610) Radio Party L3A12T /00S /00G; Philips - Österreich (ID = 70873) Radio
Party L3A12T /00S /00G; Philips - Österreich (ID = 108583) Radio Party L3A12T /00S /00G; Philips - Österreich (ID = 152916) Radio
Party L3A12T /00S /00G; Philips - Österreich (ID = 152917) Radio Party L3A12T /00S /00G; Philips - Österreich (ID = 276922) Radio
Use red slider bar for more.
Party L3A12T /00S /00G; Philips - Österreich (ID = 467367) Radio
Philips - Österreich: Party L3A12T /00S /00G [Radio] ID = 467367 728x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Party L3A12T /00S /00G, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: OC44 OC45 OC45 OC71 OC71 OC72 OC72 OA85 OA79
Main principle Superheterodyne (common); ZF/IF 460 kHz; 4 AF stage(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 2x4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Party L3A12T /00S /00G - Philips - Österreich
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 160 x 80 mm / 9.4 x 6.3 x 3.1 inch
Notes

Gegenüber dem Vorjahresmodell geändertes Gehäusedesign. Lieferbar in 2 Gehäusefarben.
Party, L3A12T/00 G,  Gehäusefarbe Grau
Party, L3A12T/00 S,  Gehäusefarbe Grün
Technisch ident mit dem Parallelgerät Hornyphon Lisette WL391T/00.
Das letzte PHILIPS-Gerät dieser Modellreihe.

Weiterführende Informationen zu diesem Modell sowie der ganzen Modellreihe in diesem Forumsbeitrag.

Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
