Philips Radios -: Saturn-Truhe 752/4E/3D FD752A [Radio] ID = 1889434 709x775

Select picture or schematic to display from thumbnails on the right and click for download.

For model Saturn-Truhe 752/4E/3D FD752A, Philips Radios - Deutschland

Country:

Germany

Manufacturer / Brand:

Philips Radios - Deutschland

Brand

Deutsche Philips-Ges.

Year: 1955–1957

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

10: ECC85 ECH81 EF89 EBF80 EM80 EABC80 UL41 EL84 UL41 EL84

Main principle	to an article Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits	8 AM circuit(s) 11 FM circuit(s)
Wave bands	Broadcast, Long Wave, Short Wave plus FM or UHF.
Details	Changer (Record changer)
Power type and voltage	Alternating Current supply (AC) / 110-220 Volt
Loudspeaker	4 Loudspeakers
Power out
from Radiomuseum.org	Model: Saturn-Truhe 752/4E/3D FD752A - Philips Radios - Deutschland
Material	Wooden case
Shape	Console with Push Buttons.
Dimensions (WHD)	800 x 875 x 420 mm / 31.5 x 34.4 x 16.5 inch
Notes	Rundfunk-Chassis = Saturn 653/4E/3D Phono-Chassis = AG1003.
Net weight (2.2 lb = 1 kg)	35 kg / 77 lb 1.5 oz (77.093 lb)
Price in first year of sale	818.00 DM
External source of data	Erb
Source of data	HdB d.Rdf-& Ferns-GrH 1955/56
Literature/Schematics (1)	-- Original-techn. papers.

All listed radios etc. from Philips Radios - Deutschland
Here you find 2518 models, 2240 with images and 1529 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Robert Forchert-Mühlbachler (A)

Collection of a member from D

Forum contributions about this model

Philips Radios -: Saturn-Truhe 752/4E/3D FD752A

Threads: 1 | Posts: 3

Hits: 718 Replies: 2 philips: Switch on back panel
Dejan Dizdar 12.Jun.17	1 philips: Switch on back panel Can anyone help me: what is the function of the switch marked in red? Attachments Switch on the back panel (251 KB)
Wolfgang Bauer 12.Jun.17	2 philips: Switch on back panel Hello Mr. Dizdar, this is the switch for the internal loudspeakers, external loudspeakers and both together. Regards WB.
Dejan Dizdar 12.Jun.17	3 philips: Switch on back panel Thank You Wolfgang!
