Saturn 852/4E/3D FD852A

Saturn 852/4E/3D FD852A; Philips Radios - (ID = 165917) Radio

Saturn 852/4E/3D FD852A; Philips Radios - (ID = 165918) Radio

Saturn 852/4E/3D FD852A; Philips Radios - (ID = 165916) Radio

Saturn 852/4E/3D FD852A; Philips Radios - (ID = 255556) Radio

Saturn 852/4E/3D FD852A; Philips Radios - (ID = 255557) Radio
Saturn 852/4E/3D FD852A; Philips Radios - (ID = 417696) Radio Saturn 852/4E/3D FD852A; Philips Radios - (ID = 417700) Radio
Saturn 852/4E/3D FD852A; Philips Radios - (ID = 417701) Radio Saturn 852/4E/3D FD852A; Philips Radios - (ID = 220721) Radio
Saturn 852/4E/3D FD852A; Philips Radios - (ID = 417697) Radio Saturn 852/4E/3D FD852A; Philips Radios - (ID = 417699) Radio
Saturn 852/4E/3D FD852A; Philips Radios - (ID = 648723) Radio Saturn 852/4E/3D FD852A; Philips Radios - (ID = 648724) Radio
Use red slider bar for more.
Saturn 852/4E/3D FD852A; Philips Radios - (ID = 417696) Radio
Philips Radios -: Saturn 852/4E/3D FD852A [Radio] ID = 417696 500x375
Select picture or schematic to display from thumbnails on the right and click for download.
For model Saturn 852/4E/3D FD852A, Philips Radios - Deutschland:
ebay 300194580678 Verkäufer bellissima1984

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: ECC85 ECH81 EF89 EBF80 EM80 EABC80 EL84 EL84 EL41 EL41
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Saturn 852/4E/3D FD852A - Philips Radios - Deutschland
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1260 x 870 x 418 mm / 49.6 x 34.3 x 16.5 inch
Notes Rundfunk-Chassis = 653;
Phono-Chassis = AG1003.
Net weight (2.2 lb = 1 kg) 54 kg / 118 lb 15.1 oz (118.943 lb)
Price in first year of sale 988.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1955/56
