• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1955/1956

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 20343

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• ECC85 ECH81 EF89 EBF80 EM80 EABC80 UL41 EL84 UL41 EL84

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Saturn-Vitrine 754/4E/3D FD754A - Philips Radios - Deutschland

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1160 x 870 x 418 mm / 45.7 x 34.3 x 16.5 inch

• Notes
• Rundfunk-Chassis = 653;
  Phono-Chassis = AG1003.

• Net weight (2.2 lb = 1 kg)
• 46 kg / 101 lb 5.1 oz (101.322 lb)

• Price in first year of sale
• 958.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1955/56

• Literature/Schematics (1)
• -- Original-techn. papers.
