ZBA-341812

ZBA-341812; Philips Ibérica, (ID = 2071905) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2071906) mod-past25

ZBA-341812; Philips Ibérica, (ID = 1330529) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077015) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077327) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077328) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077329) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077330) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077331) mod-past25

ZBA-341812; Philips Ibérica, (ID = 2077332) mod-past25
Use red slider bar for more.
ZBA-341812; Philips Ibérica, (ID = 2071905) mod-past25
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Spain
Manufacturer / Brand:  Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
Year: 1959 Category: Radio module post 1925 (not a part, not a key)
Valves / Tubes 1: ECC85
Main principle Superheterodyne (common); ZF/IF 10700 kHz
Tuned circuits 5 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Powered by external power supply or a main unit. / AC 6,3 & DC 200 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: ZBA-341812 - Philips Ibérica, COPRESA,
Material Various materials
Shape Chassis only or for «building in»
Notes

Módulo de FM usado, al menos, en los siguientes aparatos: B3E15A, B3E16A, B4E03A, B4E14A, B4E25A, F7E25A, F7E35A



Literature/Schematics (1) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
