• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1960–1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 322817

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• OC171 OC171 AF105 or. OC170 AF105 or. OC170 AF105 or. OC170 OC71 OC75 OC74 OC74 OA160 OA172 OA172

• Main principle
• Superheterodyne (common); ZF/IF 472/10700 kHz; 3 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Simonetta UKW-Transistorkoffer BT 62 UML - QUELLE GmbH Universum; Fürth

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 280 x 180 x 85 mm / 11 x 7.1 x 3.3 inch

• Notes

• Modellversion mit UMK siehe Quelle Simonetta BT62 UMK
  Parallelmodell Tonfunk BT62 UML
  Hersteller: Tonfunk GmbH Karlsruhe für Quelle Versand GmbH, Fürth

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• -- Original prospect or advert

• Author
• Model page created by Wolfgang Gebert. See "Data change" for further contributors.
