Sonate RBUT 16-2A

Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 2306416) R-Player
Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017419) R-Player Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017420) R-Player
Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017421) R-Player Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017422) R-Player
Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017423) R-Player Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017424) R-Player
Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017425) R-Player Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017426) R-Player
Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1825486) R-Player
Use red slider bar for more.
Sonate RBUT 16-2A; Bell Telephone Mfg. (ID = 1017419) R-Player
Bell Telephone Mfg.: Sonate RBUT 16-2A [R-Player] ID = 1017419 615x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sonate RBUT 16-2A, Bell Telephone Mfg. Co. (Radiobell); Antwerp:
Picture taken in the Olens Radiomuseum - Belgium

Country:  Belgium
Manufacturer / Brand:  Bell Telephone Mfg. Co. (Radiobell); Antwerp
Brand

Radiobell
Year: 1958 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: EL95 ECC83 ECC83 EL84 EM71
Semiconductors (the count is only for transistors) OA85 SR250B75
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Sonate RBUT 16-2A - Bell Telephone Mfg. Co.
Material Leather / canvas / plastic - over other material
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 300 x 185 x 335 mm / 11.8 x 7.3 x 13.2 inch
Notes

3 motors, 2 speed (4.75 & 9.5 cm/s), 3 heads, the tape reels are on top of each other, loudspeaker is MBLE AD3460/00 (100 x 150 mm)

This model is identical to ACEC Lugavox 1158. See there for a more complete technical service manual.



Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Mentioned in -- Original-techn. papers.

Model page created by Georges Van Campenhout. See "Data change" for further contributors.
