• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 312964

• • Brand: SFER

• Number of Tubes
• 10

• Valves / Tubes
• ECC85 ECH81 EF89 EBF89 ECC83 EAA91 EL84 EL84 EM80 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: RA5110A - Radiola marque

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 565 x 240 x 280 mm / 22.2 x 9.4 x 11 inch

• Notes

• Made by Philips in Leuven/Belgium (PL).

• Author
• Model page created by Eddy Rischmann. See "Data change" for further contributors.
