For model AU44 Hoch, Radione (RADIO Nikolaus Eltz); Wien:
Radione AU44 (Hochbau)

Country:  Austria
Manufacturer / Brand:  Radione (RADIO Nikolaus Eltz); Wien
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: CF7 CF3 CBC1 CL2 CY1
Main principle Superheterodyne (common); ZF/IF 128,5 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-220 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: AU44 [Hoch] - Radione RADIO Nikolaus Eltz;
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 360 x 410 x 240 mm / 14.2 x 16.1 x 9.4 inch
Notes Abstimmungs-Anzeige. Export Schweiz (Sch=Thali).
Net weight (2.2 lb = 1 kg) 10.5 kg / 23 lb 2 oz (23.128 lb)
Price in first year of sale 548.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange + Schenk
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
