Allegretto
REMA, Fabrik für: Allegretto [Radio] ID = 561568 769x650
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1956 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 8: ECC81 ECH81 EF80 EF80 EM80 EABC80 EL12 AZ12 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 468/10700 kHz |
|---|---|
| Tuned circuits | 10 AM circuit(s) 11 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 125; 220 Volt |
| Loudspeaker | 3 Loudspeakers / Ø 24.5 cm = 9.6 inch |
| Power out | 8 W (unknown quality) |
| from Radiomuseum.org | Model: Allegretto - REMA, Fabrik für Rundfunk, |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 640 x 435 x 280 mm / 25.2 x 17.1 x 11 inch |
| Notes | Gerät ist technisch baugleich dem Allegro, nur Hochtonlautsprecher schräg in den Ecken eingebaut. |
| Net weight (2.2 lb = 1 kg) | 19 kg / 41 lb 13.6 oz (41.85 lb) |
| Price in first year of sale | 650.00 DM |
| External source of data | Radio und Fernsehen 6/1956 |
| Source of data | Radiokatalog Band 2, Ernst Erb |
| Mentioned in | -- Schematic |
| Literature/Schematics (1) | Radio und Fernsehen (DDR) (7/1956, S. 196) |
Model page created by Michael Seiffert. See "Data change" for further contributors.
