Breisgau Automatic 15 de Luxe natur

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350970) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350971) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350972) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350973) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350974) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350975) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350976) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350977) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350978) Radio

Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350979) Radio
Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350967) Radio Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350968) Radio
Use red slider bar for more.
Breisgau Automatic 15 de Luxe; SABA; Villingen (ID = 1350967) Radio
SABA; Villingen: Breisgau Automatic 15 de Luxe [Radio] ID = 1350967 933x982
Select picture or schematic to display from thumbnails on the right and click for download.
For model Breisgau Automatic 15 de Luxe natur, SABA; Villingen:
By courtesy of guest Michael Dowling, volunteer for British Heart Foundation, Southport, UK.

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 13: ECC85 ECH81 EF89 EBF89 EM84 EM87 EF86 EF86 ECC83 EABC80 ECL80 ELL80 ELL80
Main principle Super-Heterodyne (Super in general)
Tuned circuits 10 AM circuit(s)     13 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 115; 127; 220; 240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Breisgau Automatic 15 de Luxe [natur] - SABA; Villingen
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1510 x 850 x 415 mm / 59.4 x 33.5 x 16.3 inch
Notes Rundfunk-Chassis = R-Baustein 15, Stereo-Decoder nachrüstbar, Stereo-NF-Verstärker mit 2 Gegentakt-Endstufen je 5,5 W;
Phono-Chassis = Dual 1009..
Abgleich (auch Steuerfilter)
Alignment (also automatic filter)
Net weight (2.2 lb = 1 kg) 71 kg / 156 lb 6.2 oz (156.388 lb)
Price in first year of sale 2,692.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965
