Meersburg W III (W3)

Meersburg W III ; SABA; Villingen (ID = 9933) Radio

Meersburg W III ; SABA; Villingen (ID = 9934) Radio

Meersburg W III ; SABA; Villingen (ID = 9936) Radio

Meersburg W III ; SABA; Villingen (ID = 9935) Radio

Meersburg W III ; SABA; Villingen (ID = 1916911) Radio
Meersburg W III ; SABA; Villingen (ID = 1315344) Radio Meersburg W III ; SABA; Villingen (ID = 70490) Radio
Meersburg W III ; SABA; Villingen (ID = 101353) Radio Meersburg W III ; SABA; Villingen (ID = 101351) Radio
Meersburg W III ; SABA; Villingen (ID = 26119) Radio Meersburg W III ; SABA; Villingen (ID = 454054) Radio
Meersburg W III ; SABA; Villingen (ID = 454055) Radio Meersburg W III ; SABA; Villingen (ID = 454056) Radio
Meersburg W III ; SABA; Villingen (ID = 454057) Radio Meersburg W III ; SABA; Villingen (ID = 474556) Radio
Use red slider bar for more.
Meersburg W III ; SABA; Villingen (ID = 1315344) Radio
SABA; Villingen: Meersburg W III [Radio] ID = 1315344 930x635
Select picture or schematic to display from thumbnails on the right and click for download.
For model Meersburg W III (W3), SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF80 EC92 ECH81 EAF42 EM35 or EM34 EABC80 EL84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Superhet with RF-stage; ZF/IF 472/10700 kHz
Tuned circuits 8 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 150; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 4.5 W (undistorted)
from Radiomuseum.org Model: Meersburg W III - SABA; Villingen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 600 x 385 x 276 mm / 23.6 x 15.2 x 10.9 inch
Notes Mit drehbarer Ferritantenne
Net weight (2.2 lb = 1 kg) 14.7 kg / 32 lb 6.1 oz (32.379 lb)
Price in first year of sale 448.00 DM
Collectors' prices
External source of data Erb
Source of data Kat.d.Rundf.GrossH.1953/54
Literature/Schematics (1) -- Original-techn. papers.
