Schauinsland T605

Schauinsland T605; SABA; Villingen (ID = 971587) Television

Schauinsland T605; SABA; Villingen (ID = 971589) Television

Schauinsland T605; SABA; Villingen (ID = 971590) Television

Schauinsland T605; SABA; Villingen (ID = 971591) Television

Schauinsland T605; SABA; Villingen (ID = 971592) Television

Schauinsland T605; SABA; Villingen (ID = 971593) Television

Schauinsland T605; SABA; Villingen (ID = 971594) Television

Schauinsland T605; SABA; Villingen (ID = 971595) Television

Schauinsland T605; SABA; Villingen (ID = 971596) Television

Schauinsland T605; SABA; Villingen (ID = 971597) Television
Schauinsland T605; SABA; Villingen (ID = 321202) Television Schauinsland T605; SABA; Villingen (ID = 372784) Television
Use red slider bar for more.
Schauinsland T605; SABA; Villingen (ID = 321202) Television
SABA; Villingen: Schauinsland T605 [Television] ID = 321202 809x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T605, SABA; Villingen:
Saba Reporter 12

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1956/1957 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: PCC84 PCF82 EF80 EF80 EF80 PCL81 ECL80 PCL82 PCL82 PL36 PY83 EY86 EF80 EF80 PABC80 MW53-80
Main principle Super-Heterodyne (Super in general); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Schauinsland T605 - SABA; Villingen
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 580 x 477 mm / 24.8 x 22.8 x 18.8 inch
Notes VHF-Band I & III.
Net weight (2.2 lb = 1 kg) 42 kg / 92 lb 8.2 oz (92.511 lb)
Price in first year of sale 1'098.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57


All listed radios etc. from SABA; Villingen
Here you find 1553 models, 1413 with images and 1041 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.





Forum contributions about this model
SABA; Villingen: Schauinsland T605
Threads: 1 | Posts: 1
Hits: 1181     Replies: 0
saba: T605 (T 605); Schauinsland
Andre Lücht
16.Apr.08
  1

Hallo, weiß zufällig jemand, wie die Typenbezeichnung des Zeilentrafos lautet?

Für Infos bedanke ich mich im Voraus.

LG  A. Lücht
