Radiowagen Olympia R573W; Sachsenwerk (ID = 61923) Radio
Sachsenwerk: Radiowagen Olympia R573W [Radio] ID = 61923 875x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiowagen Olympia R573W 3D, Sachsenwerk Niedersedlitz, VEB Elektromaschinenbau; Niedersedlitz (Ostd.)

Country:  Germany
Manufacturer / Brand:  Sachsenwerk Niedersedlitz, VEB Elektromaschinenbau; Niedersedlitz (Ostd.)
Brand

VEB Elektromaschinenbau Sachsenwerk
Year: 1956–1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM80 EL84 EZ80
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Radiowagen Olympia R573W [3D] - Sachsenwerk Niedersedlitz,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 710 x 670 x 375 mm / 28 x 26.4 x 14.8 inch
Notes Rundfunkempfänger 573W in einen «Radiowagen» mit 3-D-Klang eingebaut. Siehe auch R573WP mit Plattenspieler.
Net weight (2.2 lb = 1 kg) 29 kg / 63 lb 14 oz (63.877 lb)
Price in first year of sale 705.00 DM
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Funk-Technik (FT) (5618)
