For model E-5917, Sondyna AG; Zürich-Effretikon

Country:  Switzerland
Manufacturer / Brand:  Sondyna AG; Zürich-Effretikon
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 470 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 145; 220; 250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: E-5917 - Sondyna AG; Zürich-Effretikon
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 335 x 225 mm / 22 x 13.2 x 8.9 inch
Source of data -- Collector info (Sammler)

Model page created by Christian Schaufelberger. See "Data change" for further contributors.
