Radiola Duett 1506V

Radiola Duett 1506V; SRA Svenska (ID = 1617396) Radio

Radiola Duett 1506V; SRA Svenska (ID = 1651526) Radio
Radiola Duett 1506V; SRA Svenska (ID = 142212) Radio Radiola Duett 1506V; SRA Svenska (ID = 142213) Radio
Radiola Duett 1506V; SRA Svenska (ID = 142214) Radio Radiola Duett 1506V; SRA Svenska (ID = 142215) Radio
Radiola Duett 1506V; SRA Svenska (ID = 666218) Radio Radiola Duett 1506V; SRA Svenska (ID = 1007462) Radio
Radiola Duett 1506V; SRA Svenska (ID = 1007463) Radio Radiola Duett 1506V; SRA Svenska (ID = 1517558) Radio
Use red slider bar for more.
Radiola Duett 1506V; SRA Svenska (ID = 142212) Radio
SRA Svenska: Radiola Duett 1506V [Radio] ID = 142212 407x468
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola Duett 1506V, SRA Svenska Radioaktiebolaget; Stockholm

Country:  Sweden
Manufacturer / Brand:  SRA Svenska Radioaktiebolaget; Stockholm
Brand

Radiola
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH42 6BA6 6AT6 EL41 AZ41
Main principle Super-Heterodyne (Super in general); ZF/IF 452 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 140; 155; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Radiola Duett 1506V - SRA Svenska Radioaktiebolaget;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 350 x 245 x 310 mm / 13.8 x 9.6 x 12.2 inch
Notes

Plattenspieler mit elektro-magnetischen System und auswechselbarer Stahlnadel. (Fa. Garrard Eng. & MFG. Co. Ltd.; Swindon, England) Skalenlampe: 6,5 V, 0,2 A

Siehe auch ähnliches SRA Exportmodell Ericsson 1506AC.

Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Collectors' prices
Source of data -- Schematic

Model page created by Klaus Dräger. See "Data change" for further contributors.
