Imperial 60WK M-Schrank

ID = 4949

Imperial 60WK; Stassfurter Licht- (ID = 1801382) Radio

Imperial 60WK; Stassfurter Licht- (ID = 1801383) Radio

Imperial 60WK; Stassfurter Licht- (ID = 14808) Radio

{gbW: "933", gbH: "756", mW: "462.0", mH: "375", kb: "134 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]Mai 2011, Sonderausstellung im Rundfunkmuseum der Stadt Fürth: Musikschränke - Giganten im Wirtschaftswunder-Wohnzimmer.", title: "Stassfurter Licht- Imperial 60WK from Museum: Rundfunkmuseum Fürth (1)", ite: "1"} {gbW: "933", gbH: "730", mW: "479.0", mH: "375", kb: "113 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]Imperial Musikschrank 60 WK", title: "Stassfurter Licht- Imperial 60WK from Alexander Herrmann (1)", ite: "1"} {gbW: "700", gbH: "482", mW: "500", mH: "344.0", kb: "83 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter)", title: "Stassfurter Licht- Imperial 60WK uploaded by Ernst Erb (2)", ite: "2"} {gbW: "700", gbH: "933", mW: "281.0", mH: "375", kb: "149 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]Mai 2011, Sonderausstellung im Rundfunkmuseum der Stadt Fürth: Musikschränke - Giganten im Wirtschaftswunder-Wohnzimmer.", title: "Stassfurter Licht- Imperial 60WK from Museum: Rundfunkmuseum Fürth (1)", ite: "1"} {gbW: "723", gbH: "933", mW: "290.0", mH: "375", kb: "159 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]Mai 2011, Sonderausstellung im Rundfunkmuseum der Stadt Fürth: Musikschränke - Giganten im Wirtschaftswunder-Wohnzimmer.", title: "Stassfurter Licht- Imperial 60WK from Museum: Rundfunkmuseum Fürth (1)", ite: "1"} {gbW: "640", gbH: "480", mW: "500", mH: "375", kb: "50 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]D_Musikschrank 60WK_1minsk.jpg", title: "Stassfurter Licht- Imperial 60WK uploaded by Anton Gorsky (2)", ite: "2"} {gbW: "640", gbH: "480", mW: "500", mH: "375", kb: "58 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]D_Musikschrank 60WK_2minsk.jpg", title: "Stassfurter Licht- Imperial 60WK uploaded by Anton Gorsky (2)", ite: "2"} {gbW: "532", gbH: "449", mW: "444.0", mH: "375", kb: "47 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]D_Musikschrank 60WK_ausKiew.jpg", title: "Stassfurter Licht- Imperial 60WK uploaded by Anton Gorsky (2)", ite: "2"} {gbW: "525", gbH: "700", mW: "281.0", mH: "375", kb: "42 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter)", title: "Stassfurter Licht- Imperial 60WK uploaded by Christoph Thiele (2)", ite: "2"} {gbW: "500", gbH: "375", mW: "500", mH: "375", kb: "40 KB", notes: "For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):[br]Ebay DE 280573681614 kp-tuning10 (ohne Typenangabe)", title: "Stassfurter Licht- Imperial 60WK uploaded by RM Member (sID 38) (2)", ite: "2"}

Imperial 60WK; Stassfurter Licht- (ID = 1023802) Radio

Imperial 60WK; Stassfurter Licht- (ID = 944513) Radio

Imperial 60WK; Stassfurter Licht- (ID = 1039) Radio

Imperial 60WK; Stassfurter Licht- (ID = 1023803) Radio

Imperial 60WK; Stassfurter Licht- (ID = 1023804) Radio

Imperial 60WK; Stassfurter Licht- (ID = 114469) Radio

Imperial 60WK; Stassfurter Licht- (ID = 114470) Radio

Imperial 60WK; Stassfurter Licht- (ID = 114471) Radio

Imperial 60WK; Stassfurter Licht- (ID = 415304) Radio

Imperial 60WK; Stassfurter Licht- (ID = 837184) Radio

Next pictures

Use red slider bar for more.

Stassfurter Licht-: Imperial 60WK [Radio] ID = 1023802 933x756

Select picture or schematic to display from thumbnails on the right and click for download.

For model Imperial 60WK M-Schrank, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter):
Mai 2011, Sonderausstellung im Rundfunkmuseum der Stadt Fürth: Musikschränke - Giganten im Wirtschaftswunder-Wohnzimmer.

Country:

Germany

Manufacturer / Brand:

Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter)

Year: 1939–1941

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

6: ECH11 EF11 EBF11 EL11 EM11 AZ11

schematic requested

Main principle	Superheterodyne (common); ZF/IF 477 kHz
Tuned circuits	6 AM circuit(s)
Wave bands	Broadcast, Long Wave and Short Wave.
Details	Record Player (perh.Changer)
Power type and voltage	Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker	2 Loudspeakers
Power out
from Radiomuseum.org	Model: Imperial 60WK [M-Schrank] - Stassfurter Licht- und
Material	Wooden case
Shape	Console with any shape - in general
Dimensions (WHD)	955 x 840 x 430 mm / 37.6 x 33.1 x 16.9 inch
Notes	Ch= 60WK.
Net weight (2.2 lb = 1 kg)	45.9 kg / 101 lb 1.6 oz (101.101 lb)
Price in first year of sale	645.00 RM
Source of data	Katalog Eltax, Berlin, 1939/40 / Radiokatalog Band 1, Ernst Erb
Mentioned in	Fortschritte der Funktechnik und ihrer Grenzgebiete (8 Bände) (6)
Picture reference	Das Modell ist im «Radiokatalog» (Erb) abgebildet.
