Maestro Luxussuper W816 EM80

Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 996258) Radio

Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 996259) Radio

Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 996260) Radio

Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 996257) Radio
Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 469886) Radio Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 2317691) Radio
Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 2318074) Radio Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 2318073) Radio
Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 2318080) Radio Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 2318075) Radio
Use red slider bar for more.
Maestro Luxussuper W816; Südfunk-Apparatebau, (ID = 469886) Radio
Südfunk-Apparatebau,: Maestro Luxussuper W816 [Radio] ID = 469886 456x276
Select picture or schematic to display from thumbnails on the right and click for download.
For model Maestro Luxussuper W816 EM80, Südfunk-Apparatebau, Dr. Ing. Robert Ott; Stuttgart

Country:  Germany
Manufacturer / Brand:  Südfunk-Apparatebau, Dr. Ing. Robert Ott; Stuttgart
Year: 1957–1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EF89 EM80 EABC80 EL84 EZ80
schematic requested
Main principle Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Maestro Luxussuper W816 [EM80] - Südfunk-Apparatebau, Dr. Ing.
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 610 x 350 x 260 mm / 24 x 13.8 x 10.2 inch
Notes

dreh- und abschaltbare Ferritantenne.

Paralleltype zum Quelle Simonetta 3D Luxus Breitform Luxus.

Net weight (2.2 lb = 1 kg) 10.3 kg / 22 lb 11 oz (22.687 lb)
Price in first year of sale 408.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1957/58 / Radiokatalog Band 2, Ernst Erb
