Admiral 346GL-220V (T346GL)

Admiral 346GL-220V ; Telefunken (ID = 13300) Radio

Admiral 346GL-220V ; Telefunken (ID = 13301) Radio

Admiral 346GL-220V ; Telefunken (ID = 21737) Radio

Admiral 346GL-220V ; Telefunken (ID = 718158) Radio

Admiral 346GL-220V ; Telefunken (ID = 718159) Radio

Admiral 346GL-220V ; Telefunken (ID = 7621) Radio
Admiral 346GL-220V ; Telefunken (ID = 711526) Radio Admiral 346GL-220V ; Telefunken (ID = 711626) Radio
Admiral 346GL-220V ; Telefunken (ID = 521121) Radio Admiral 346GL-220V ; Telefunken (ID = 456784) Radio
Admiral 346GL-220V ; Telefunken (ID = 711623) Radio Admiral 346GL-220V ; Telefunken (ID = 523673) Radio
Admiral 346GL-220V ; Telefunken (ID = 711621) Radio Admiral 346GL-220V ; Telefunken (ID = 1508462) Radio
Admiral 346GL-220V ; Telefunken (ID = 1518409) Radio Admiral 346GL-220V ; Telefunken (ID = 1769767) Radio
Use red slider bar for more.
Admiral 346GL-220V ; Telefunken (ID = 711526) Radio
Telefunken: Admiral 346GL-220V [Radio] ID = 711526 933x755
Select picture or schematic to display from thumbnails on the right and click for download.
For model Admiral 346GL-220V (T346GL), Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RENS1819 RENS1819 REN1814 RENS1823d EU
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 Special; 1 AF stage(s); Anode bend detection
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Direct Current supply (DC) / 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Admiral 346GL-220V - Telefunken Deutschland TFK,
Material Bakelite case
Dimensions (WHD) 440 x 325 x 305 mm / 17.3 x 12.8 x 12 inch
Notes

Paralleltype zum AEG Ultra-Geadem 304GL in anderem Gehäuse.
Paralleltype zum Siemens Ätherzepp 47GL in anderem Gehäuse.

Price in first year of sale 265.00 RM !
Source of data Radio-Zentrale Prohaska 1933/34 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Literature/Schematics (1) Telefunken-Werkstattbuch
Picture reference Eine Abbildung findet sich im Doppelband "Radio von gestern"
