Telefunken: FE12/43St [Television] ID = 424269 504x700
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1956/1957 | Category: Television Receiver (TV) or Monitor | ||||
| Valves / Tubes | 17: PCC84 PCF82 EF80 EF80 EF80 PL83 ECC82 ECC82 PCL81 ECH81 PL81 PY83 DY80 EF80 PABC80 PL82 MW43-69 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 25750 kHz |
|---|---|
| Wave bands | Wave Bands given in the notes. |
| Details | Radio Control (+Remote Wire etc) |
| Power type and voltage | Alternating Current supply (AC) / 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch |
| Power out | |
| from Radiomuseum.org | Model: FE12/43St - Telefunken Deutschland TFK, |
| Material | Wooden case |
| Shape | Console with any shape - in general |
| Dimensions (WHD) | 520 x 840 x 445 mm / 20.5 x 33.1 x 17.5 inch |
| Notes | VHF-Band I & III. |
| Net weight (2.2 lb = 1 kg) | 33 kg / 72 lb 11 oz (72.687 lb) |
| Price in first year of sale | 898.00 DM |
| External source of data | Erb |
| Source of data | HdB d.Rdf-& Ferns-GrH 1956/57 |
