Netzanschlußgerät NA6
Telefunken: Netzanschlußgerät NA6 [Power-S] ID = 2500898 1127x2100
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1937 ? | Category: Power supply/conditioner or battery or charger | ||||
| Valves / Tubes | Te60 3-9V2,2A |
|---|
| Wave bands | - without |
|---|---|
| Details | Power Supply (not only Batt.El.) |
| Power type and voltage | Alternating Current supply (AC) / 110-240 Volt |
| Loudspeaker | - - No sound reproduction output. |
| Power out | |
| from Radiomuseum.org | Model: Netzanschlußgerät NA6 - Telefunken Deutschland TFK, |
| Material | Metal case |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 225 x 315 x 215 mm / 8.9 x 12.4 x 8.5 inch |
| Notes |
Netzanschlussgerät NA6 für den Betrieb der Empfänger KW.E.a und LW.E.a. |
| Net weight (2.2 lb = 1 kg) | 19 kg / 41 lb 13.6 oz (41.85 lb) |
| Mentioned in | Funkgeschichte der GFGF (Heft 58 aus 1988 S.15 ff Reparaturbericht) |
Model page created by Iven Müller. See "Data change" for further contributors.
