Rondo 55/TS

Rondo 55/TS; Telefunken (ID = 61953) Radio

Rondo 55/TS; Telefunken (ID = 61955) Radio

Rondo 55/TS; Telefunken (ID = 61959) Radio

Rondo 55/TS; Telefunken (ID = 61956) Radio

Rondo 55/TS; Telefunken (ID = 61957) Radio

Rondo 55/TS; Telefunken (ID = 61958) Radio
Rondo 55/TS; Telefunken (ID = 167032) Radio Rondo 55/TS; Telefunken (ID = 472580) Radio
Rondo 55/TS; Telefunken (ID = 1941719) Radio Rondo 55/TS; Telefunken (ID = 1941720) Radio
Rondo 55/TS; Telefunken (ID = 1941721) Radio Rondo 55/TS; Telefunken (ID = 149728) Radio
Rondo 55/TS; Telefunken (ID = 149730) Radio Rondo 55/TS; Telefunken (ID = 149732) Radio
Rondo 55/TS; Telefunken (ID = 149734) Radio Rondo 55/TS; Telefunken (ID = 149735) Radio
Use red slider bar for more.
Rondo 55/TS; Telefunken (ID = 167032) Radio
Telefunken: Rondo 55/TS [Radio] ID = 167032 933x664
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rondo 55/TS, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM80 EL84
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Rondo 55/TS - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 590 x 395 x 276 mm / 23.2 x 15.6 x 10.9 inch
Notes Kurzwellenspreizung / KW-Lupe
Paralleltype zum AEG 3074WD.
Net weight (2.2 lb = 1 kg) 11.6 kg / 25 lb 8.8 oz (25.551 lb)
Price in first year of sale 369.00 DM
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
Literature/Schematics (1) Radio und Fernsehen (DDR) (11-1954, Seite 323)
Literature/Schematics (2) -- Original-techn. papers.
