Quadrifoglio

Quadrifoglio ; Ultravox; Milano (ID = 1070296) Radio Quadrifoglio ; Ultravox; Milano (ID = 1070297) Radio
Quadrifoglio ; Ultravox; Milano (ID = 1070298) Radio Quadrifoglio ; Ultravox; Milano (ID = 1070299) Radio
Quadrifoglio ; Ultravox; Milano (ID = 1463249) Radio Quadrifoglio ; Ultravox; Milano (ID = 2044196) Radio
Quadrifoglio ; Ultravox; Milano (ID = 2044198) Radio Quadrifoglio ; Ultravox; Milano (ID = 2044199) Radio
Quadrifoglio ; Ultravox; Milano (ID = 2044200) Radio Quadrifoglio ; Ultravox; Milano (ID = 2044201) Radio
Use red slider bar for more.
Quadrifoglio ; Ultravox; Milano (ID = 1070296) Radio
Ultravox; Milano: Quadrifoglio [Radio] ID = 1070296 564x552
Select picture or schematic to display from thumbnails on the right and click for download.
For model Quadrifoglio, Ultravox; Milano:
Vista frontale

Country:  Italy
Manufacturer / Brand:  Ultravox; Milano
Year: 1968–1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: BF194 BF194 BF255 BF195 BF195 BF195 BC158 BC148 AC186 AC187 AA119 AA119 AA119 Tr.Gl.=Metal-rectif.
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 145; 220 / 8 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: Quadrifoglio - Ultravox; Milano
Material Modern plastics (no Bakelite or Catalin)
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 120 x 120 x 140 mm / 4.7 x 4.7 x 5.5 inch
Notes

Design Luigi Bandini Buti. Uguale al modello Alpha 2 RK501 della Siemens (Germania).
Impiega inoltre raddrizzatore B30/C400 e diodi AA119 (3) e BB117 (1).
Risposta di mercato alla TS502 della Brionvega.

Model page created by Salvatore Baldi † 2017. See "Data change" for further contributors.
