Atlas FM-OL 34PT-S4

Atlas FM-OL 34PT-S4; Vanguard; Hospitalet (ID = 284528) Radio
Use red slider bar for more.
Atlas FM-OL 34PT-S4; Vanguard; Hospitalet (ID = 284528) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Spain
Manufacturer / Brand:  Vanguard; Hospitalet de Llobregat
alternative name

Cahué Industrial
Year: 1965 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF114 AF115 AF116 AF116 AF116 AF116 AC126 AC126 AC128 AC128 OA70 OA70 OA70 OA79
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 125; 220 / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 inch = 11.4 cm
Power out
from Radiomuseum.org Model: Atlas FM-OL 34PT-S4 - Vanguard; Hospitalet de
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes Transistors: AF114, AF115, 4× AF116, 2× AC126, 2× AC128; Diodes: 3× OA70, OA79.
Literature/Schematics (1) -- Schematic

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
